Marine Electrical Cable Marine Grade Wire
While Marine Electrical Cable are special wires and cables for power, lighting, control, communication, microcomputer
and other systems of various ships, offshore oil platform and water buildings.
Due to the harsh operating conditions, cables are required to be safe and reliable,
have a long lifespan, small size, light weight, and have excellent temperature resistance,
fire resistance, flame retardancy, oil resistance, moisture resistance, seawater resistance,
as well as excellent electrical and mechanical properties. Marine power cable is a type of marine cable.
Similar to the main classification of wire and cable, marine cables devide into marine power cables
(including low-voltage power cables with rated voltage and power frequency AC 1kV and below,
While medium voltage power cables with rating voltage and power frequency AC 3-15kV), marine control cables, marine communication cables,
marine signal cables, and marine radio frequency cables according to their scope of use.
While a commonly used series of standards for marine cables, the IEC 60092-3 standard mainly includes
IEC 60092-350 “Electrical Installations in Ships – Part 350: Power, Control,
While Instrumentation Cables for Ships and Offshore Installations, General Structures and Test Methods”,
IEC 60092-360 “Electrical Installations in Ships – Part 360: Insulation and Sheathing Materials for
Power, Control, Instrumentation, and Communication Cables for Ships
While Offshore Installations” IEC 60092-353 “Electrical installations in ships – Part 353:
Power cables with rated voltages of 1kV and 3kV”, IEC 60092-354 “Electrical installations in ships – Part 354:
Single core and multi-core extruded solid insulated power cables with rated voltages of 6kV (Um=7.2kV) to 30kV (Um=36kV)”,
While IEC 60092-376 “Marine electrical and pneumatic installations – Part 376: Control and instrument loop 150/250V (300V) cables”.
The rapid development of the shipbuilding industry will further drive the market demand for marine cables.
Affected by the working environment of ships, Marine Electrical Cables Video pls contact us!
